Manta Ray 2018 DF01 4WD Kit Tamiya 47367

This reissue of the Manta Ray is certainly news to celebrate for fans of Tamiya's vintage 4WD buggy models! The body - inspired by the aquatic stingray of the natural world - is still a classic nearly 30 years after its original release in 1990; The body and large rear spoiler are molded from lightweight and durable polycarbonate. Sleek, solid-rimmed wheels are paired with studded tires for exceptional grip on or off-road. For those looking for even higher performance, why not pair our dedicated Hop-Up Option parts set?

The 4WD chassis of this kit is based around a tub frame with a honeycomb rib pattern for excellent rigidity, and which also facilitates a low center of gravity thanks to a low mounting position for the battery. Its 4-wheel independent double wishbone suspension uses CVA oil shocks, while the lightweight and durable hollow lower arms feature a smooth design to prevent dirt from sticking to it. The differentials are contained in sealed gearboxes, each with a quick-access maintenance hatch. The 3-piece tie rod provides precise response, and the tie rods make it easy to change the toe angle.

• 1/10 RC chassis with four-wheel drive (cardan drive).
• Robust bathtub frame.
• Four-wheel independent suspension and double wishbones.
• Constant volume hydraulic shock absorbers.
• Two differentials under sealed housings.
• Quick-access maintenance hatches.
• Adjustable front toe.
• Grippy Aero rims and studded tires.
• Aerodynamic bodywork inspired by the shapes of the manta ray.
• Original decorative stickers.
• 540 motor and drive included.

Characteristics:

★ Length: 395 mm, width: 250 mm, height: 145 mm
★ Wheelbase: 270 mm
★ Weight (excluding R/C equipment and battery): 1,100 g
★ Tread: 207mm (front and rear)
★ Bathtub-type frame frame
★ Shaft - 4WD
★ 3-bevel front/rear differentials
★ 3-piece tie rod
★ 4-wheel double wishbone suspension
★ Tire width/diameter: 40/84 mm (front and rear)
★ CVA Short Oil Shock Absorbers
★ Gear ratio = 8.59:1 (with 21T sprocket included in the kit)
★Type 540 engine
★Requires electronic speed controller (sold separately)

Equipment NOT included:

2-way radio, servo, ESC (electronic speed control), 7.2 volt battery and charger, and Tamiya PS paint.
