Jet EDF F-22 Raptor Twin Turbine 40mm Approx. 702mm PNP XFly

XFly Model is proud to announce its first full-scale F-22 Raptor jet in the dual 40mm EDF range. In an effort to make it as streamlined and true-to-scale as possible, the XFly team is equipping the F-22 with a twin-turbine system configuration and reserving scale details including the air intake, cockpit, nozzle, and horizontal axes of full flight.

The factory-installed propulsion system, featuring two efficient 1413-KV5000 brushless motors and two 20A brushless controllers, paired with a 4S LiPo battery, provides abundant thrust for quick climbs, rolls, loops, and endless high-bank flying fun thanks to the F-22's low wing loading and full flight capabilities. A flight time of about 3 to 8 minutes can be achieved with good throttle management.

The perfectly fitting landing gear design helps to keep the aircraft light and make take-off and landing smooth. The landing gear can be easily removed for increased speed and vertical performance. Thanks to the F-22's low-speed capability, you can even easily grip the aircraft by hand when landing.

Features:

- Streamlined, true-to-scale design
- Efficient dual propulsion system configuration provides maximum thrust for quick climbs, rollovers, and loops
- Low wing loading
- Perfectly adjusted landing gear design for a smooth take-off and landing
- Extended flight time of 3-8 minutes using the recommended 4S 1300-2600mAh LiPo battery
- 5 x 9g servo motors
- 2x20A brushless ESC
- 2 x 1413-KV5000 brushless motors
- EDF turbines 2 x 40 mm
- All components can be assembled quickly without the need for glue
- Molded handles for easy hand launch

Characteristics:

Wingspan: 702 mm
Total length: 955 mm
Wing loading: 89 g/dm²
Wing area: 10.6 dm²
Flying weight: 950 g
Engine : 2 x 1413-KV5000
ESC: 2 x 20 A (XT60)
Servos: 5 x 9 g servos
CG: 80 mm from leading edge
EDF Size: 2 x 40MM EDF 12 Blades
Retractable: No
Shutter: No
Landing gear: Fixed main landing gear, steerable nose gear
Recommended Radio: Minimum 5 channels
Recommended Environment: Outdoor
Battery Capacity: 4S 1300-2600mAh
Flight time: 3 to 8 minutes
Assembly time: approx. 10 minutes

Essentials not included:

- Minimum 5-way remote control and receiver
- Li-Po 4S 14.8V 1300 - 2600 mAh XT60 socket
- Li-Po charger
